Built for performance, the L901 uses Memjet Waterfall Printhead Technology® to produce sharp, high-resolution labels at speeds of up to 12 inches per second. Its stationary printhead design and “on-the-fly” maintenance capability ensure smooth, uninterrupted operation—ideal for long print runs or integration with applicators, finishers, and dispensers.
The L901 is equipped with five high-capacity dye-based ink cartridges (CMYKK), delivering an ultra-low cost per label. For applications requiring extra durability, the L901 Plus is available with Watershield™ water-resistant inks—ideal for chilled beverage, food, chemical, or pharmaceutical labels.
Pair the L901 with an XL Unwinder/Rewinder system to enable full roll-to-roll production, reducing media costs and handling time. Compatible with a wide range of substrates, including paper, polypropylene, polyester, and vinyl.
Print System:
• Print Technology: Memjet Waterfall Printhead Technology®
• Printhead: 11 IC Chips, 70,400 nozzles
• Resolution: 1600 x 1600 dpi or 1600 x 800 dpi
• Print Width: Up to 8.5” (216 mm)
• Print Speed: 6 to 12 inches/sec (152 to 305 mm/sec)
• Cutter: Powered automatic cutter
Ink System:
• Ink Type: Dye-based CMYKK (5 cartridges total)
• Cartridge Size: 250 mL each (1.25 L total capacity)
• Optional: Watershield™ water-resistant inks (L901 Plus model)
Media Handling:
• Media Width: 2” – 9” (50.8 – 229 mm)
• Media Length: 2” – 48” (50.8 – 1220 mm)
• Media Thickness: 0.005” – 0.01” (0.13 – 0.3 mm including liner)
• Label Gap: 0.125” – 0.3” (3.0 – 8.0 mm)
• Sensors: Gap (movable), black mark, continuous
• Compatible Substrates: Paper, polyester, polypropylene, vinyl
• Core Diameter: 3” (76.2 mm)
• Max Roll OD: 10” (250 mm)
Connectivity & Software:
• Interfaces: USB 2.0, TCP/IP (manual or DHCP), GPIO
• OS Compatibility: Windows 7, 8, 10 (32/64-bit)
• Barcode Printing:
• 1D: Grade B (Code39, 10 mil bar width)
• 2D: Grade B (PDF417, 10 mil cell size)
Environment & Electrical:
• Operating Temperature: 15°–35°C (59°–95°F), RH 20–80%
• Voltage: AC 110V–220V, auto-sensing
Size & Weight:
• Dimensions (W x D x H): 22.5” x 20.5” x 14” (572 x 521 x 356 mm)
• Weight: 85 lb (38.5 kg)
