Triumph

Triumph 6660 Paper Cutter [USED]

$14,999.00 CAD Sold out
Pre-owned
Shipping calculated at checkout.

The MBM Triumph 6660 programmable paper cutter is designed for precision and efficiency in high-volume cutting environments. Featuring an automatic clamp and power back gauge, it ensures smooth, accurate cuts with every use. The user-friendly digital touchpad allows for easy programming, making operation simple and fast. This Triumph 6660 paper cutter is equipped with IR safety light beams on the front table and prioritizes user protection during operation. Ideal for offices, print shops, and commercial businesses, the Triumph 6660 combines powerful performance with advanced safety features, providing consistent, high-quality results for all your paper-cutting needs.

More about the product

  • Programmable cutter with automatic clamp
  • Power back gauge
  • Digital Touchpad
  • Patented easy cut electronic blade activation bars for true two-hand operation
  • Ergonomic, 37" working height
  • Electric blade and clamp drive
  • Electric back gauge drive with touchpad for easy programming
  • Digital measurement display (cm or inches) with multilingual perator guidance, accurate to 1/10 mm or 1/100 inch
  • Stores 99 programs with up to 99 steps in each (up to 15 repeat cuts can be integrated as a single step)
  • Pre-programmed for standard paper sizes. Memory key for repeat cuts
  • Automatic set function for reference measurement and eject function for pushing out paper
  • Self-diagnostic system with error indication on the display
  • Electronic back gauge control with variable speed control for manual back gauge setting

    Bright, LED optical cutting line
  • 3-step, LED front table illumination
  • Adjustable, spindle guided back gauge with narrow separations and plastic gliders
  • Dual side guides on front and rear tables
  • Solid steel blade carrier and adjustable blade guides
  • All-metal construction
  • Includes stand with storage shelf, easy-access tool holder, and paper blocking tool
  • Optional side tables increase the work surface
  • UL and C UL approved

With the reliable Triumph 6660 you get a paper cutter with superior cutting capabilities, top notch safety package, and the most up to date innovative features making the 6660 extremely easy to operate. It can cut documents and formats up to 25 ½” in length and 3” in height, and perform a narrow cut of just under 1”. The 6660 is equipped with an Easy Cut system, in which the blade and clamp are activated independently via the activating bars. Each have separate trigger points on the activating bars. This will allow for actually safe two hand operation.

When it comes to safety, you can’t find a safer professional paper cutter on the market today than the Triumph 6660. It is stocked with a comprehensive safety package (SCS), which includes a unique IR safety curtain. This transparent safety curtain features an innovative IR light barrier that is located on the front table (working area). This great safety guard locks upon operation and if anything penetrates the light beam safety curtain, operation will instantly hault. There is also a safety cover on the rear table, main switch, and safety lock (with key) as apart of the comprehensive safety package. The SCS also includes a handy tool holder as well as a convenient blade changing device. The tool holder is hooked onto the back table and keeps all tools needed for blade changes and service jobs together, organized, and well within reach. The blade changing device makes changing the blade very easy and safe. You don’t even have to remove any of the 6660’s covers and the device covers the cutting edge of the blade for user protection.

The reliable 6660 paper cutter is also well equipped with the newest innovative features that make this paper cutter even easier to use. Instead of the old standard keypad control panel, the 6660 has an easy-to-use touch pad, which makes operating this machine much more convenient. The touchpad is multilingual and can store up to 99 programs, and each program can have up to 99 steps. Not only can you store 99 programs into the touchpad’s high capacity memory, it can also store repeat and frequent cuts. This electronic touchpad also enables users for easy positioning of the back gauge. However, the 6660 has an electronic handwheel, which is perfect for manually positioning of the backgauge. The handwheel is very useful because it has infinitely variable speed control from very slow to very fast.

Features

• Electric Paper Cutter

• Cutting Width: 25 1/2″

• Cutting Height: 3″

• Length Behind Blade: 24″

• Narrow Cut: 1″

• Clamp Type: Automatic



Product Details

• Item #: CU0492V

• Blade Material: German steel

• Horsepower: 2

• Electrical Requirements: 115 V. 60 Hz., 20-amp dedicated line

• Dimensions (D x W x H): 48″ x 39″ x 51″ (61 1/2″ W with side tables)

• Shipping Weight: 775 lbs. (796 with side tables)
