MULTIGRAF
PRINT FINISHER
This side-by-side analysis provides a clear overview of Multigraf print finishing machines, helping you evaluate performance, capacity, and compatibility. Use it to identify the best solution for your workflow and optimize efficiency!
MIN PAPER SIZE
4.13" W x 5.83" L
8.26" W x 8.26" L
8.26" W x 8.26" L
MAX PAPER SIZE
14.76" W x 26" L (Optional upgrade to 41.34" L)
13" W x 29.5" L (Optional upgrade to 39.37" L)
13" W x 27.95" L (Optional upgrade to 39.37" L)
MIN FINISHED SIZE
3.5" W x 1.97" L
1.89" W x 1.97" L
1.89" W x 1.97" L
FEEDER STACK HEIGHT
7.09"
3.9"
4.72"
FEED SKEW ADJUSTMENT
Yes
Yes
Yes (auto notification)
MIN PAPER WEIGHT
80 gsm (perf and/or cutting) / 100 gsm (creasing)
110 gsm
110 gsm
MAX PAPER WEIGHT
300 gsm (perf) / 400 gsm (Creasing and/or cutting)
400 gsm
400 gsm
SLITTING
Yes (Up to 6 per sheet)
Yes (up to 6 per sheet)
Yes (6 per sheet standard, upgradeable to 8)
CUTTING
Yes
Yes
Yes
CREASING
Yes
Yes
Yes
CREASE WIDTH ADJUSTMENT
Yes (thin & thick options)
Yes (thin & thick options)
Yes (thin & thick options)
CREASE DEPTH ADJUSTMENT
Yes
Yes
Yes
DOWN CREASING
Yes
Yes
Yes
UP CREASING
Yes (with optional module)
No
Yes (with optional module)
CROSS PERFORATION
Yes
Optional (reduces slitting by 2)
Optional (reduces slitting by 2)
LENGTH PERFORATION
Yes (2 included, upgradeable to 4)
Optional (reduces slitting by 2)
Optional (reduces slitting by 2)
PERFORATION OPTIONS
Standard, Fine and Micro
Standard and Micro
Standard and Micro
OPERATOR INTERFACE
12" HMI Touchscreen
PC Laptop and/or HMI Touchscreen
PC Laptop and/or HMI Touchscreen
MAX SHEETS PER MINUTE (8.5"X11")
33
23
40
FULL BLEED BUSINESS CARD PER MINUTE
336
216
288
