VRCut Ready Triumph 6660 Paper Cutter

$0.00 CAD

The VRCut Ready Triumph 5260 Paper Cutter is a powerful, programmable electric cutter designed for precision and efficiency. With a cutting width of 20 3/8 inches and a maximum height of 3 inches, it can handle various paper sizes. Key features include an automatic clamp, an electric back gauge, and a digital touchpad for easy programming. The Triumph 5260 paper cutter can store up to 99 programs and supports narrow cuts as small as 1 3/8 inches, making it highly versatile. Designed for ergonomic operation, the paper cutter is equipped with German steel blades, LED optical cutting lines, and a patented safety drive. These features ensure smooth, safe, and accurate cuts, making this paper cutter ideal for high-volume environments.
Download Brochure
Product Description

Safety Features:
• IR light beam safety curtain on the front table
• Safety cover on rear table
• Main switch and safety lock with key
• 24-volt controls (low voltage)
• Patented IDEAL safety drive
• Automatic blade and clamp return from every position
• Disc brake for instant blade stop
• Blade changing device covers cutting edge of the blade
• Blade depth adjustment from outside of the machine
• Blade and cutting stick can be changed without removing covers

Characteristics:
• Programmable cutter with automatic clamp
• Power back gauge
• Digital Touchpad
• Patented easy cut electronic blade activation bars for true two-hand operation
• Ergonomic, 37" working height
• Electric blade and clamp drive
• Electric back gauge drive with touchpad for easy programming
• Digital measurement display (cm or inches) with multilingual operator guidance, accurate to 1/10 mm or 1/100 inch
• Stores 99 programs with up to 99 steps in each (up to 15 repeat cuts can be integrated as a single step)
• Pre-programmed for standard paper sizes. Memory key for repeat cuts
• Automatic set function for reference measurement and eject function for pushing out paper
• Self-diagnostic system with error indication on the display
• Electronic back gauge control with variable speed control for manual back gauge setting
• Bright, LED optical cutting line
• 3-step, LED front table illumination
• Adjustable, spindle guided back gauge with narrow separations and plastic gliders
• Dual side guides on front and rear tables
• Solid steel blade carrier and adjustable blade guides
• All-metal construction
• Includes stand with storage shelf, easy-access tool holder, and paper blocking tool
• Optional side tables increase the work surface
• UL and C UL approved
Product Specifications

• Electric Paper Cutter
• Cutting Width: 25 1/2″
• Cutting Height: 3″
• Length Behind Blade: 24″
• Narrow Cut: 1″
• Clamp Type: Automatic
• Blade Material: German steel
• Horsepower: 2
• Electrical Requirements: 115 V. 60 Hz., 20-amp dedicated line
• Dimensions (D x W x H): 48″ x 39″ x 51″ (61 1/2″ W with side tables)
• Shipping Weight: 775 lbs. (796 with side tables)
